When stored indoors in original, unopened containers at temperatures between 40° – 90° F (4° – 32° C), optimum performance and best use is obtained within one year of date of manufacture.
- Complies with U.S. EPA, LADCO, OTC, SCAQMD, and all other current North American VOC regulations.
- Treated surface is USDA accepted.
VOC Content: 0 g/L
Surface Preparation … Fresh Concrete: On newly placed concrete, LIQUI-HARD can be applied after final troweling. Existing (Old) Concrete:Surface should be clean and structurally sound. Remove all residues, curing compounds, oils, sealers, contaminants, and laitance before applying LIQUI-HARD. ULTRITE® DEGREASER from W. R. MEADOWS may be used for cleaning. Fill and repair all holes, cracks, and deteriorated areas that have been removed to sound concrete.
For optimum results on fresh, newly placed concrete, use MED-CURE™ curing aid from W. R. MEADOWS immediately after final finishing operations have been completed. Apply LIQUI-HARD according to the below existing concrete directions a minimum of three days after placement of concrete.
Mixing … For optimum performance, gentle mixing or agitation is recommended.
Application Method … Fresh Concrete: Apply undiluted LIQUI-HARD at approximately 300 ft.2/gal. (4.91 m2/L) using a low-pressure sprayer, such as a Chapin 1949 with a 0.5 GPM (1.9 LPM) spray nozzle, or by spreading evenly with a soft-bristled broom. Do not allow material to puddle on the surface. No further application steps are required for fresh concrete.
Existing (Old) Concrete: Saturate the surface with undiluted LIQUI-HARD by sprayer, squeegee or broom. Keep the surface wet with LIQUI-HARD for a minimum of 30 minutes. (A range of 30 – 60 minutes may be required depending on temperature and conditions.) NOTE: Pay particular attention to porous and/or dry areas. These areas must be kept wet at all times with LIQUI-HARD. Once the surface begins to gel and becomes slippery, immediately spray the surface with a light water mist. Scrub the surface with a broom or mechanical scrubber to increase the penetration of the LIQUI-HARD. Continue to work the LIQUI-HARD into the surface for another 5 – 10 minutes or until LIQUI-HARD becomes gelled and slippery for a second time. At this time, THOROUGHLY flush the surface with water. During the flushing process, agitate the surface with a broom to aid in removal of the excess LIQUI-HARD. Remove all excess material with a mop or squeegee. Thoroughly squeegee the surface dry. If there are slippery patches, this is an indication that there is still excess LIQUI-HARD present. These areas should be re-flushed and squeegeed again until the entire surface is dry. (Extremely porous surfaces may require a second application.)
WARNING: Failure to thoroughly wash and remove all excess material from floor surfaces may result in unsightly white stains. Immediately wash off over-spray from glass, aluminum, or highly polished surfaces with water to avoid etching of surfaces. For application assistance, contact W. R. MEADOWS at (800) 342-5976.
Burnishing … LIQUI-HARD can be burnished to a high sheen on steel trowel concrete floors. A high-speed burnisher (2000 – 2200 rpm) with appropriate maintenance pad is needed.
Drying Time … 2 – 4 hours. LIQUI-HARD dries very quickly on new, virgin concrete. Drying times may be extended on existing (old) concrete due to surface conditions. Restrict foot traffic for at least four hours; 12 hours is preferable.
Cleanup … While still wet, equipment may be cleaned quickly and easily with soap and water. Do not allow LIQUI-HARD to dry before flushing excess from surfaces.
DO NOT DILUTE. Do not apply if the temperature of the concrete is less than 35˚ F (2˚ C) or above 135˚ F (57˚ C). KEEP FROM FREEZING. If frozen, product should be thawed and agitated slightly prior to use.
LIQUI-HARD is non-combustible. (Flash point is greater than 210˚ F.) Direct contact will result in irritation of the skin and eyes. Inhalation of product mist may result in respiratory irritation. Refer to Safety Data Sheet for complete health and safety information.
