Dayton swift lift anchors

The Dayton Superior Swift Lift Eye Anchor (P53) is similar to the P52 anchor but has an eye at the foot to accept P60 Tension Bars. The P53 anchor is used primarily in thin sections, thin panels of lightweight concrete or shapes that must be handled at concrete compressive strengths below 2,000 psi. P53 anchors are available in 1, 2, 3, 4, 8 and 16 T capacities and each has its load rating embossed on the head. NOTE: P60 Tension Bar must be used with this anchor to achieve loads.
